De Chart 'n Machine Jams, Solid!

One solid JSON jam lay down de whole scene: yo washer and iron under machine, and one entry for every stack o’ dirty rags under chart. Both de CLI and de web app’s upload be diggin’ exactly dis shape, Jack — dat’s what @washy-washy/core’s parseConfig be checkin’ out, solid.

{
  "machine": { "washer": { "..." }, "iron": { "..." } },
  "chart": [{ "clothing_type": "..." }]
}

De Chart, Solid

Each entry under chart be one stack o’ rags, dig:

Field	What goes in it
`clothing_type`	Whatchu call dat stack, Jack — dis be de card’s big ol’ headline
`detergent`	Which soap jam you throwin’ in, and how much o’ dat stuff
`fabric_softener`	`yes` or `no`
`temperature`	A heat setting yo machine done offer up
`spin`	A spin speed yo machine be throwin’ down
`duration`	‘Bout how long dat thing be runnin’, jive as `~H:MM`
`program`	A dial spot, spelled just like it say right there on de fascia, no jivin’ around
`options`	Option buttons, pipe-separated; leave it empty if ain’t none
`ironing`	`yes` or `no` — whether you be ironin’ dat thing at all
`ironing_notes`	Talk: how you iron dat jam, or why you don’t mess with it. Mostly empty
`iron_setting`	A thermostat spot. Empty when `ironing` be `no`
`drying`	Talk: how you dry dat thing out
`colour_group`	`white`, `colour`, `dark`, `sport` or `any`
`mix_tags`	Pipe-separated, dig: `lint-shedder`, `lint-magnet`, `dye-bleeder`, `solo`
`notes`	Anything else worth knowin’, solid

Every machine-facin’ jive — program, temperature, spin, options, iron_setting — get checked against what yo own machine be offerin’, so a typo gonna bust wit’ de exact row ’n column ‘stead o’ cookin’ up a card dat tell you to crank de dial someplace it don’t even go, Jack.

De Machine, Jack

machine.washer be listin’ de dial’s labels in de order they really sit, plus de heat settings, spin speeds and option buttons de display be throwin’ down. machine.iron be listin’ de thermostat’s spots, from coolest all de way to scorchin’. Copy every label just like it’s printed right in front o’ yo face, whatever language dat happen to be — ain’t nothin’ here ever translatin’ a fascia label, ‘cause a chart you gotta translate back while you standin’ at de machine be worse than no chart at all, dig?

De order o’ washer.programs be totin’ de whole weight: de first entry be de off position, drawn up at twelve o’clock, and every other tick’s angle come straight from where it be sittin’ in dat list. Leave one out and you ain’t just droppin’ it — you movin’ every tick dat come after, solid.

De web app’s own /config/machine editor be writin’ dis same shape — shufflin’ de programme list up in there do exactly what shufflin’ de JSON array would, no jive:

De machine editor's spin speeds, buttons 'n iron settings table, laid out solid

{
  "washer": {
    "name": "Generic front loader",
    "capacity": "1–8 kg",
    "programs": ["Off", "Cottons", "Delicates / Silk", "Wool"],
    "temperatures": ["cold", "20", "30", "40", "60", "90"],
    "spins": ["0", "400", "600", "800", "1200", "1400"],
    "options": ["Speed", "Eco", "Easy Iron", "Extra Rinse"]
  },
  "iron": {
    "name": "Generic steam iron",
    "settings": [
      {
        "key": "min",
        "dots": "",
        "label": "MIN",
        "detail": "no heat",
        "steam": false
      },
      {
        "key": "3",
        "dots": "•••",
        "label": "•••",
        "detail": "cotton, linen · 200 °C",
        "steam": true
      }
    ]
  }
}

What Can Get Down Together in De Wash

Two stacks o’ rags can only share a drum when all o’ dis check out, in order — de first one dat come up bust be de reason a compatibility matrix woulda showed you, dig:

Neither one be tagged solo, Jack.
If either one be a lint-shedder, de other one gotta be too, no exceptions.
Their colour_group be matchin’ up (any matches everything, solid).
program, temperature, spin and de whole set o’ options be dead-on identical.

Stacks merge up onto one card, sharin’ a single dial drawin’, when everything you physically set be agreein’: programme, temperature, spin, options, whether softener be goin’ in, and where dat iron’s thermostat be pointin’. Talk fields (detergent, drying, notes) ain’t part o’ dat check on purpose — two stacks can want different soap and still share one card, and de card lay down both lines against de stack they belong to, solid.
